Plastic Air Diffusers
Introducing for the first time, Aditya One Piece Plastic Air Diffuser - Fit it Forget it product for HVAC Industries. Our One Piece Plastic Air Diffuser replaces Aluminum and Metal Diffuser in all Industries. It is available in 4 - Way Flow Pattern. One Piece Plastic Air Diffuser are highly cost effective compared to metal diffusers. They are manufactured from one piece mould with appropriate thickness for higher strength. One Piece Plastic Diffusers are available in Step Down and Flash Type with removable core. It is easy to attach VCD in Flash Type Removable Core Diffuser. Step Down Diffuser is the fastest product replacing metal diffuser in Textile Spinning and Weaving Mills.
Below are comparison and advantages chart of our One Piece Plastic Air Diffuser.
| Sr.No. | Aluminium Diffuser | Aditya - Air Diffuser |
|---|---|---|
| 1 | Separation from corner after some time or if collide anywhere. | No Corner Separation as it is made from One Piece Moulded Frame. |
| 2 | Getting bend or de-shape if collide while installing or during transportation or during cleaning, etc. | Plastic Diffuser does not get bend even if collide as it is made from Engineering Plastic ABS. |
| 3 | Higher noise level due to obstruction in flow of air because of edges for fitting on back side of diffuser. | Very negligible noise of air flow due to finish surface even on back side which also increases air flow output. |
| 4 | Higher cost. | Approximate 25-30% Cheaper compared to Aluminum Diffuser. |
| 5 | Load on duct due to weight of diffuser. | Lighter Weight due to Plastic material and hence no load on duct. |
| 6 | Rusting & Corrosion in chemical industries. | No Rusting and Corrosion due to plastic material. It can be used in any chemical industries. Also most viable for Pharmaceutical industries. |
| 7 | Radiation due to metal where medical equipment and machineries are installed. | No Radiation because of Plastic Material. We have already installed in X-Ray and CT Scan Areas in Hospitals. |
| 8 | Difficult to install and takes longer time for installation. | Easy to Install. Just Fit it Forget it. |
| 9 | Special care to be taken during cleaning and maintenance. | Easy to clean and wash and again ready to use. |
| 10 | Low thickness of Blades which can bend and vibrate easily. | Higher Thickness of Frames varies from 2.25 mm to 3.5 mm. |
